Bushing Bearing Series H315 Hydraulic Gear Pump (Motor)

Features:

·High strength, perfect efficiency, long wear life, suited for heavy load and wretched environment. It also has excellent performance in high temperature and low low viscosity situation.

·High strength Iron casting, external gear pump
·Antifriction bushing bearing

·Advanced pressure-balanced thrust plate and special seal structure.

·The pump (motor) has the characteristics of serialization, standardization, and generalization. Double and multiple assemblies are available. Pump and motor have a wide selection of mounting connection type, connection dimension is SAE standard.

HP315 Hydraulic Gear Pump Performance Data

Flow mL/rev	G.W in	Rated Pressure MPa	Max Pressure MPa	Speed RPM Highest lowest	Input power KW
7.6	3/8＂	24.1	28	3000 600	10
10.2	1/2＂	24.1	28	3000 600	13
12.7	5/8＂	24.1	28	3000 600	17
15.2	3/4＂	24.1	28	3000 600	20
17.8	7/8＂	24.1	28	3000 600	23
20.3	1＂	24.1	28	3000 600	26
22.9	1 1/8＂	24.1	28	3000 600	30
25.4	1 1/4＂	24.1	28	3000 600	33
27.9	1 3/8＂	24.1	28	3000 600	36
30.5	1 1/2＂	22.8	26.2	3000 600	37
33.0	1 5/8＂	21.4	24.8	3000 600	38
35.6	1 3/4＂	20.0	23	3000 600	38
38.1	1 7/8＂	18.6	21.4	3000 600	37
40.6	2＂	17.2	20	3000 600	38

HM315 Hydraulic Motor Performance Data

Flow ml/rev	Iput flow 2400 RPM LPM	G.W	Rted pressure MPa	Max ressure MPa	speed RPM Highest lowest	Output power KW	Otput troque Nm
20.3	46	1＂	21.4	24.8	3000 600	13.2	63
25.4	56	1 1/4＂	21.4	24.8	3000 600	16	76.4
30.5	66	1 1/2＂	18	21	3000 600	25.8	123.2
35.6	78	1 3/4＂	18	21	3000 600	18.9	90.3
40.6	89	2＂	17.2	20	3000 600	20.7	98.9
