Roller Bearing H76 Series Hydraulic Gear Pump (Motor)

Current Location：Home - Product Center - Product display - Hydraulic pump / motor - Roller bearing series

Product Name：Roller Bearing H76 Series Hydraulic Gear Pump (Motor)
Product Id：212641-753
Update Time：2012.11.24
Views：
More Images：

Overview Features Model Orders Certification

Roller Bearing Series H76 Hydraulic Gear Pump (Motor)

Features:

·Compact structure, small volume, low noise, high pressure, wide flow range

·High strength Iron casting, external gear pump
·Second-seal structure, to improve pump’s performance.

·Thrust plate, with special structure and special surface treatment, make our pump better pressure-proof and antiwear.

·Special structure bearings, provide better capacity for heavy load and impaction.

·The pump (motor) has the characteristics of serialization, standardization, and generalization. Double and multiple assemblies are available. Pump and motor have a wide selection of mounting connection type, connection dimension is SAE standard.

HP76 Hydraulic Gear Pump Performance Data

Flow mL/rev	G.W in	Rated Pressure MPa	Max pressure MPa	speed RPM Highest Lowest	Input power KW
67.19	1＂	20.7	24.2	2400 600	64
83.99	1 1/4＂	20.7	24.2	2400 600	79.5
100.78	1 1/2＂	20.7	24.2	2400 600	95
117.58	1 3/4＂	20.7	24.2	2400 600	110.5
134.37	2＂	17.2	20.7	2400 600	105
151.18	2 1/4＂	17.2	20.7	2400 600	118
167.97	2 1/2＂	17.2	20.7	2400 600	132
184.77	2 3/4＂	13.8	17.2	2400 600	116
201.56	3＂	13.8	17.2	2400 600	126

HM76 Hydraulic Motor Performance Data

Flow ml/rev	Input flow 2000 RPM LPM	G.W in	Rated Pressure MPa	Max pressure MPa	Speed RPM Highest Lowest	Output power KW	Output troque Nm
67.19	157	1＂	20.7	24.2	2200 600	43.5	207.8
100.78	223	1 1/2＂	20.7	24.2	2200 600	61.8	295.2
134.37	295	2＂	17.2	20.7	2200 600	68	324.8
167.97	365	2 1/2＂	17.2	20.7	2200 600	84.5	403.7
201.56	431	3＂	13.8	17.2	2200 600	81.5	387
